Ailunce HA1G Scanning Function Operation Steps

JJ
Dec 31,2024
- 0
Ailunce HA1G, GMRS RADIO, HA1G GMRS Radio (green), long range

Ailunce HA1G is a GMRS walkie-talkie suitable for beginners. It has IP67 waterproof, 256 channels, weather alarm, emergency alarm, supports front panel operation, and is easy to learn. Whether it is camping with family or private communication with friends, Ailunce HA1G is a reliable and affordable choice for beginners. The following introduces the operation steps of the scanning function of this walkie-talkie.

1. Set the name of the scan list

Press the menu key, enter the list and select scan, click the menu key, click the scan list alias, the up and down keys can move, the return key can delete the named characters, and the menu key is to save.

2. Scan static condition

You can set static or sub-tone static.

1>Press [Up] or [Down] to select "Scan stop condition", press [MENU] to enter.

2>Press [Up] or [Down] to switch pause and sub-tone stop

3>Press [MENU] to confirm and return.

4>Press [EXIT] to return without saving.

Carrier scan: After turning on channel scan, regardless of whether the current channel has sub-tone, as long as the carrier matches (frequency matches), reception is turned on.

CTC/DCS scan: If the channel has sub-tone, sub-tone matching is required during scanning before reception can begin

3. Scan mode

which can be set to vehicle scan, time scan, or search scan

1> Press [Up] or [Down] to select "Scan mode", and press [MENU] to enter.

2> Press [Up] or [Down] to switch between vehicle scan, time scan, and search scan.

3> Press [MENU] to confirm and return.

4> Press [EXIT] to return without saving.

4.Send mode setting

when triggering transmission during scanning, the selected transmission mode can be set to current channel transmission, last active channel transmission, or specified channel transmission.

1> Press [Up] or [Down] to select "Send mode setting", and press [MENU] to enter.

2> Press [Up] or [Down] to switch between the current channel, the last active channel, and the specified channel.

3> Press [MENU] to confirm and return.

4> Press [EXIT] to return without saving.

5.Specified send channel selection

If a specified channel is set in the send mode, the radio will send on the channel selected here.

1> Press [Up] or [Down] to select "Specified send channel selection", press [MENU] to enter.

2> Press [Up] or [Down] to switch to the specified channel.

3> Press [MENU] to view.

4> Press [EXIT] to return.

6.Priority channel 1

you can select a priority channel from all channels to scan

1> Press [Up] or [Down] to select "Priority channel 1", press [MENU] to enter.

2> Press [Up] or [Down] to switch to the priority channel.

3> Press [MENU] to view.

4> Press [EXIT] to return.

7.Priority Channel 2

Same as "Priority Channel 1".

8.Channel List

the channel list here is the channel that needs to be scanned when the scanning function is turned on, and up to 16 channels can be added.

Scan list broadcast channel settings; you can rotate the headset to move the mouse, and then press EXIT to delete the scanned channel

9.Dwell time

After scanning the wireless channel, the channel signal disappears, and you can adjust the time to stay on this wireless channel by rotating the channel knob (the runway will light orange during the dwell time)

1> Press [MENU] to enter the setting interface.

2> Press [Up] or [Down] or rotate [Channel] to select the signaling list.

3> Press [MENU] to confirm the selection and exit.

4> Press [EXIT] to return without saving.

Ailunce HA1G 5W IP67 Rugged GMRS Radio

Ailunce HA1G is a GMRS walkie-talkie suitable for beginners. It has 5W high power and is equipped with 8 repeater channels, which can be used with repeaters for long-distance communication. In addition, the IP67 waterproof and rugged material and built-in 2800mAh battery make HA1G rugged GMRS radio for long-term use. It also has basic functions required for outdoor communication, such as VFO, hands-free operation and weather alerts. Whether camping with family or making long-distance private calls with friends, Ailunce HA1G is a reliable and affordable choice for beginners.
